1.5v 3v 4.5v Mini Dc Gear Toy Motor with Reduction Plastic Gearbox for Toy / Toy Car / Robot
1.5v 3v 4.5v Mini Dc Gear Toy Motor with Reduction Plastic Gearbox for Toy / Toy Car / Robot
1.5v 3v 4.5v Mini Dc Gear Toy Motor with Reduction Plastic Gearbox for Toy / Toy Car / Robot
1.5v 3v 4.5v Mini Dc Gear Toy Motor with Reduction Plastic Gearbox for Toy / Toy Car / Robot
1.5v 3v 4.5v Mini Dc Gear Toy Motor with Reduction Plastic Gearbox for Toy / Toy Car / Robot
1 / 5
1.5v 3v 4.5v Mini Dc Gear Toy Motor with Reduction Plastic Gearbox for Toy / Toy Car / Robot
1.5v 3v 4.5v Mini Dc Gear Toy Motor with Reduction Plastic Gearbox for Toy / Toy Car / Robot
1.5v 3v 4.5v Mini Dc Gear Toy Motor with Reduction Plastic Gearbox for Toy / Toy Car / Robot
1.5v 3v 4.5v Mini Dc Gear Toy Motor with Reduction Plastic Gearbox for Toy / Toy Car / Robot
1.5v 3v 4.5v Mini Dc Gear Toy Motor with Reduction Plastic Gearbox for Toy / Toy Car / Robot

1.5v 3v 4.5v Mini Dc Gear Toy Motor with Reduction Plastic Gearbox for Toy / Toy Car / Robot

Send Inquiry

Product Description

1.5v 3v 4.5v Mini DC Gear Toy Motor with Reduction Plastic Gearbox for Toy / Toy Car / Robot
Promotion
1.5v 3v 4.5v Mini Dc Gear Toy Motor with Reduction Plastic Gearbox for Toy / Toy Car / Robot Promotion Banner
Our motors have long life, high efficiency and good stability. Insert the drive inside the motor to capture data more accurately.
1.5v 3v 4.5v Mini Dc Gear Toy Motor Structure Diagram
Mini Dc Gear Toy Motor Gearbox Detail
Characters
Model Voltage No-load Load Stall
Working Voltage (V) Rated voltage Speed Current Speed Current Torque Power output Stall torque Current
V rpm A rpm A N.m Kg.m W N.m Kg.m A
SGP01S-A130-14150-120 3-12.0V 4.5 100 0.2 87 0.5 0.066 0.675 0.4 0.265 2.7 1.25
SGP01S-A130-18100-220 3-12.0V 3.0 50 0.2 40 0.3 0.120 1.233 0.6 0.393 4.003 2.15
Technical Drawing of Gear Motor Dimensions
Mini DC Motor for Toy Production
Mini DC Motor Components Display
Manufacturing Line Details
Motor Varieties Selection
Micro DC Gear Motor Options
FAQ
Are you a trading company or a manufacturer?
We are a factory. We specialize in micro DC motors and DC gear motors for more than 14 years.
What is the payment term for a new customer?
We can draw up an Online Assurance Order for our new customers, which can be paid online with Master Card, Visa, etc. Customers can also pay via PayPal, TT, and other standard payment methods.
I can't find a suitable motor on your website, can you customize the motor for me?
Yes, we can customize a suitable motor according to our customer's specific requirements.
Do you have certificates for the motors?
Yes, we have CE, FCC, ISO, etc. If you have other specific certificate requirements, we can apply for them for you.
How is your Quality Control?
We have professional inspection staff on every production line process. After finishing the motor assembly, we use professional testing machines to evaluate the quality. This includes a Hardness Tester, 2.5D Image Tester, Salt Spray Chamber, Life Tester, Temperature Test Machine, and Noise tester, among others.
What is the typical lead time for custom orders?
Lead times vary based on design complexity and quantities required, but typically customized samples take 10-15 days, and production orders take 25-30 days.
