SRC-370SH-4730 Factory Hot selling 4.5V 17500rmp 3.63A output 11.51W

Product Description

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
		Operating Range	Nominal	Speed	Current	Speed	Current	Torque	Power	Current	Torque
		Operating Range	Nominal	RPM	mA	RPM	mA	mN.m / gf.cm	W	mA	mN.m / gf.cm
RF-370CA	061700	6.0~24.0	24 VDC	1320	3	1000	8	0.98/10	0.1	260	4.02/41
RC-370CH	20123	3.0~6.0	6 VDC	8000	70	6878	420	2.4/24.5	1.71	2550	17/173
RC-370SH	4730	3.0~5.0	4.5 VDC	17500	550	15199	3630	7.2/73.4	11.51	24000	55/561
RC-370SH	18139	6.0~12.0	12 VDC	10000	130	8439	700	5.8/59.2	5.17	3800	37.5/382.5

Note: Please refer to the parameters above to select the appropriate model variant for your application.

Application

Frequently Asked Questions

What are the primary specifications of the SRC-370SH-4730 motor?

The SRC-370SH-4730 is a high-performance PMDC motor designed for a nominal operating voltage of 4.5V VDC. It features a high rated speed of 15,199 RPM, a rated current of 3.63A (3630 mA), and delivers an output power of 11.51W.

What is the operating voltage range for the RC-370SH series?

The operating range depends on the specific model. For the 4730 model, the range is 3.0V to 5.0V. For the 18139 model, the range is 6.0V to 12.0V, with a nominal voltage of 12V VDC.

What are the typical applications of these micro DC motors?

These motors are widely used in consumer electronics, automotive components, smart home systems, robotic devices, health equipment, and various compact industrial automation mechanisms requiring precise PMDC performance.

What is the stall performance of the RC-370SH 4730 variant?

At stall conditions, the RC-370SH 4730 model produces a stall torque of 55 mN.m (561 gf.cm) with a stall current draw of 24,000 mA (24A).

How do the RF-370 and RC-370 models compare in parameters?

The RF-370CA has a broader operating range (6.0V to 24.0V) and lower speed characteristics (1,320 RPM no-load), making it suitable for low-power, high-voltage requirements. The RC-370SH series is designed for higher speeds (up to 17,500 RPM no-load) and higher power outputs at lower nominal voltages.
