MicroDyn Motor
1 / 4
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| RPM | A | RPM | A | mN.m / gf.cm | W | A | mN.m / gf.cm | ||||
| RS-750H | 7032R | 6.0~12.0 | 12 VDC | 15000 | 1.79 | 12671 | 7.52 | 48.6 / 496 | 66.6 | 55.6 | 393.1 / 4010 |
| RS-755H | 7512R | 3.0~6.0 | 6 VDC | 9500 | 2.26 | 8123 | 9.31 | 45.1 / 460 | 38.2 | 66.34 | 306.9 / 3130 |
These high-performance PMDC motors are highly versatile and widely integrated across various industries, including smart home appliances, power tools, automotive components, and automated industrial machinery.
We operate specialized motor factories with over 14 years of professional manufacturing experience. Equipped with advanced production lines, a mature R&D department, and highly skilled engineering staff, we guarantee consistent quality and high output.
To ensure reliability, strict inspection protocols are enforced from raw materials sourcing to final packaging. Our rigorous QC standards form the foundational basis for long-term product durability and performance.
